Medical Oxygen Concentrator
Hyperbaric Oxygen Therapy (HBOT)
Hyperbaric Oxygen Therapy
Features
- Users can choose 60 mins, 90 mins, or 120 mins of working time according to their needs, which is convenient to use;
- The oxygen concentration in the chamber is controlled within 25%, ensuring the safety of users;
- The display can show oxygen concentration, temperature, humidity and pressure;
- It can ensure that the CO2 in the oxygen chamber does not exceed 6000ppm;
- Medical TPU high-strength pressure-resistant nano-material, environmentally friendly and tasteless.
Specification
| Model | JAY-1.3HB/JAY-1.4HB/JAY-1.5HB |
|---|---|
| Type | O2&Air in one / O2&Air&Air Dryer three in one |
| O2&Air Flowrate | 5L/min&60L/min (20psi) / 10L/min&100L/min (20psi) |
| Air&O2 Automatic Control System | Pressurize the chamber by air at 120L/min within 6 mins; booster mixed 93%±3% oxygen at 5L/min and air 60L/min automatically after 6 mins (for 5L type) / Pressurize the chamber by mixed 93%±3% oxygen at 10L/min and air 100L/min (for 10L type) |
| Cooling System | Fan & Cooler / Air dryer |
| Chamber Capsule Full-filled Time | 10 mins / 8 mins |
| Soft Chamber | Soft (Sitting/Lying) |
| Available Pressure | 1.3ATA/1.4ATA/1.5ATA |
| Size | 1600*650*1200mm / 2100*850*2020mm |
Hyperbaric Oxygen Therapy
Features
- Users can choose 60 mins, 90 mins, or 120 mins of working time according to their needs, which is convenient to use;
- The oxygen concentration in the chamber is controlled within 25%, ensuring the safety of users;
- The display can show oxygen concentration, temperature, humidity and pressure;
- It can ensure that the CO2 in the oxygen chamber does not exceed 6000ppm;
- Medical TPU high-strength pressure-resistant nano-material, environmentally friendly and tasteless.
Specification
| Oxygen Concentrator | Type | O2&Air in one | O2&Air&Air Dryer three in one |
|---|---|---|---|
| O2&Air flowrate | 5L/min&60L/min (20psi) |
10L/min&100L/min (20psi) |
|
| Air&O2 automatic control system | Pressurize the chamber by air at 120L/min within 6 mins; booster mixed 93%±3% oxygen at 5L/min and air 60L/min automatically after 6 mins | Pressurize the chamber by mixed 93%±3% oxygen at 10L/min and air 100L/min | |
| Cooling system | Fan&Cooler | Air dryer | |
| Chamber capsule full-filled time | 10 mins | 8 mins | |
| Soft Chamber | Type | Soft (Sitting/Lying) | |
| Available pressure | 1.3ATA/1.4ATA/1.5ATA | ||
| Size | 1600*650*1200mm / 2100*850*2020mm | ||
